Description
- Does not melt / Carbonisation above +370°C
- Comply to DIN EN6049-003-02-5
- Made of non-flammable meta-aramid
- Water and oil-repellent
- Extremely flexible
- High expansion for easy installation over long lengths
- Optimal mechanical protection for harnesses
- Able to withstand the most severe environments
- Superior protection against abrasion, flames, and high temperatures
- Highly resistant to radiation, microorganisms, and fluids
- Also, very resistant to acids and alkali
Certifications & Approvals:
Application:
HEGMANWO is especially resistant to water and oil and is designed for applications requiring mechanical protection at high temperatures, particularly in the aerospace, military, railway, and ship-building industries.
| TYPE | Bundle Ø min. | Bundle Ø max. |  Colour | Reel Length |  Article-No. |
| HEGMANWO-02 | 1 | 2 | Green (GN) | 100 m | 170-02000 |
| HEGMANWO-04 | 2 | 4 | Green (GN) | 100 m | 170-02001 |
| HEGMANWO-06 | 4 | 8 | Green (GN) | 100 m | 170-02002 |
| HEGMANWO-08 | 6 | 12 | Green (GN) | 50 m | 170-02003 |
| HEGMANWO-10 | 8 | 16 | Green (GN) | 50 m | 170-02004 |
| HEGMANWO-15 | 10 | 20 | Green (GN) | 50 m | 170-02005 |
| HEGMANWO-20 | 12 | 24 | Green (GN) | 50 m | 170-02006 |
| HEGMANWO-25 | 15 | 30 | Green (GN) | 50 m | 170-02007 |
| HEGMANWO-30 | 20 | 40 | Green (GN) | 50 m | 170-02008 |
All dimensions in mm. Subject to technical changes.
Cuts in any lengths. NOMEX® is a registered trademark of DuPont. Minimum Order Quantity (MOQ) may differ from package content.
Document:
HT_Catalogue_HEGMANWO Series
